Light duty drawer slide with hold-out





Model: 3688HO Light duty drawer slide with hold out



Mounting: side

Hole pattern: standard

Type: ball bearing drawer slide

Travel: Full extension

Finish:



  • Clear Zinc-plated(ZP)
  • Black Zinc-plated(BZP)
  • Black Electric Dipping (BED)
  • Yellow Zinc-plated(YZP)




Length: 250mm~700mm

Clearance: 12.7mm(0.5″)

Height: 36mm(1.42″)



http://www.slide-maker.com/3688HO.html
