Drawer slide Specifications 規格: Profile 滑軌截面尺寸 :   Side space滑軌間隙 - 19mm(0.75") , Height高度 - 58mm(2.28") Extension 展長 :    Full extension slide 全部展出 ,( Option選擇 : Overtravel 1" 超展 1inch ) Load rating 荷重 :  255 LBS (116KGS) Size 滑軌長度: Customer size Finish 表面處理 :    Clear Zinc-plated(ZP)白鋅電鍍 , Black Zinc-plated(BZP)黑鋅電鍍 , Black Electric Dipping (BED)電著黑色 , Yellow Zinc-plated(YZP)五彩鍍鋅. Material 材料 :  Work hardened cold rolled steel 冷軋鋼. Drawer slide Features 特徵: Action sequence in both directions by two stage detent function.          在兩個方向上的行動順序由兩個階段的制動功能。 Bumpers ensure quiet movement by preventing metal contact.          擋套確保安靜的移動，防止金屬碰撞 Silent movement         靜音滑動。 Slide should free fall at 20 degree +0/-5 degree in the horizontal position. Drawer slide Applications :  For the bottom of pull-out larder unit. Heavy lateral filing cabinets 重型橫式檔案櫃. Large storage drawers 大型儲存抽屜. Electronic racks電子機架， Anywhe

Drawer slide specifications 規格: Profile 滑軌截面尺寸 :   Side space滑軌間隙 - 19.0 mm(0.75"), Height高度 - 57mm(2.244") Extension 展長 :   Full extension 全部展出 , ( Option選擇 : Overtravel 1" ~2" 超展 1inch~2inch ) Load rating 荷重 :  200 LBS (91KGS) Size 滑軌長度:  12" to 30". Finish 表面處理 : Clear Zinc-plated(ZP)白鋅電鍍 , Black Zinc-plated(BZP)黑鋅電鍍, Black Electric Dipping (BED)電著黑色 . Material 材料 :  Work hardened cold rolled steel 冷軋鋼. Drawer slide features 特徵:  Action sequence in both directions by two stage detent function. 在兩個方向上的行動順序由兩個階段的制動功能。 Mounting by side . 直立式側裝 Fish mouth hold-in 魚嘴咬合 Non-disconnect, Silenced. 不可拆，靜音。 Drawer slide applications 應用 : . Heavy lateral filing cabinets . Large storage drawers . Electronic racks . Full extension and heavy-duty load capacity . Pedestal files cabinets  適用於橫式檔案櫃，直立式檔案櫃，及重型櫃體。 SLIDE-MAKER (MACHINERY) EXPORT CORP. SLIDE YOUR WAY Welcome to visit our websit

Drawer Slides Specifications 規格: Drawer slide Profile 滑軌截面尺寸 :   Side space滑軌間隙 - 12.7 mm (0.75") , Height高度 - 45.6 mm (1.80") Drawer slide Size 滑軌長度:  250mm - 700mm Drawer slide Finish 表面處理 :    Clear Zinc-plated(ZP)白鋅電鍍 , Black Zinc-plated(BZP)黑鋅電鍍, Black Electric Dipping (BED)電著黑色 , Yellow Zinc-plated(YZP)五彩鍍鋅. Drawer slide Material 材料 :  Work hardened cold rolled steel 冷軋鋼. Drawer Slides Features 特徵: With trigger release disconnect for easy drawer removal. Silent movement 32mm hole pattern with direct access mounting. Side space adjust adjustable tabs With soft-closing cylinder device .     使用葉片分離裝置為方便抽屜移除。     靜音滑動。     32mm孔位，直接安裝     側邊調整片     緩衝迴歸裝置 Drawer Slides Applications 應用 : Commercial and residential desk/credenza drawer , 商業和住宅書桌或餐具櫥具抽屜， Various institutional and  contract applications where full extension is required.  各種樣式需應用全展滑軌產品。 SLIDE-MAKER (MACHINERY) EXPORT CORP. SLIDE YOUR WAY

Drawer slide Specifications 規格: Profile 滑軌截面尺寸 : Side space滑軌間隙 - 12.7 mm (0.75") , Height高度 - 45.6 mm (1.80") Size 滑軌長度:  250mm - 700mm Finish 表面處理 : Clear Zinc-plated(ZP)白鋅電鍍 , Black Zinc-plated(BZP)黑鋅電鍍, Black Electric Dipping (BED)電著黑色 , Yellow Zinc-plated(YZP)五彩鍍鋅. Material 材料 :  Work hardened cold rolled steel 冷軋鋼. Drawer slide Features 特徵: With trigger release disconnect for easy drawer removal.     使用葉片分離裝置為方便抽屜移除。 Silent movement     咬合功能，靜音滑動。 32mm hole pattern with direct access mounting.     32mm孔位，直接安裝 Side space adjust adjustable tabs     側邊調整片 With plastic self-closing device.     旋臂自關裝置 Drawer slide Applications 應用 : Commercial and residential desk/credenza drawer , 商業和住宅書桌或餐具櫥具抽屜， Various institutional and  contract applications where full extension is required.  各種樣式需應用全展滑軌產品。 SLIDE-MAKER (MACHINERY) EXPORT CORP. SLIDE YOUR WAY Welcome to visit our website :  http://www.slide-maker.com/ Keywords of this page :

3523- Desktop magnifier drawer slide  Drawer slide Specifications 規格: Slide Profile 滑軌截面尺寸 : Side space滑軌間隙 - 9.5mm(0.375") , Height高度 - 35mm(1.38") Slide Extension 展長 :  75% 3/4展出.                        Load rating 荷重 :  50 LBS (23KGS) Size 滑軌長度:  customized size Finish 表面處理 :  Clear Zinc-plated(ZP)白鋅電鍍, Black Zinc-plated(BZP)黑鋅電鍍, Black Electric Dipping (BED)電著黑色, Yellow Zinc-plated(YZP)五彩鍍鋅. Material 材料 :  Work hardened cold rolled steel 冷軋鋼. Drawer slide features 特徵: Low profile , Simple installation.     低滑軌截面尺寸，安裝簡單 Non-handed, Silent movement.     不分左右邊，靜音滑動 Drawer slide applications 應用 : Desktop magnifier.     閱讀放大器 SLIDE-MAKER (MACHINERY) EXPORT CORP. SLIDE YOUR WAY Welcome to visit our website : http:// www.slide-maker.com/   Keywords of this page :  鋼珠滑軌、路軌、導軌、軸承滑軌、軸承導軌、  drawer slide , ball bearing drawer slide ,  slide , rail , runner industrial drawer slides , telescopic drawer slides , full extension slides
